Electro-Hydraulic OT Table

Electro-Hydraulic OT Table Specification

Design
Modern, Modular

Height
Min 650 mm to Max 1000 mm (Adjustable)

Specific Usage
Operating Room, Surgical Procedures

General Use
Hospital and Medical Facility

Dimension (L*W*H)
Approx. 2100 mm x 520 mm x 650-1000 mm

Regional Style
Hospital/Clinical

Furniture Type
Operating Table

Material
Stainless Steel, Composite materials

Metals Type
Stainless Steel

Folded
No

Function
Multi-functional: Trendelenburg, Reverse Trendelenburg, Lateral Tilt, Back Section Adjustment, Leg Section Adjustment

Back Rest Lifting Angle
0 to 80

Size
Standard OT Table Size

Weight
Approx. 150 kg

Maximum Loading
250 kg

Feature
Height Adjustable, Hydraulic, Remote Controlled, Anti-rust, Easy to Clean, Mobile with Locking Wheels

Battery Backup
Yes, typically for 4-6 hours

Lateral Tilt
±20°

Leg Section Range
-90° to +15°

Tabletop Material
Radiolucent, suitable for C-arm imaging

Shoulder Rest
Detachable and adjustable

Head Section Range
-90° to +30°

Trendelenburg/Reverse Trendelenburg
±25°

Control Method
Handheld Remote and Foot Switch

Mattress
Antistatic, waterproof

Color
Stainless Steel / Black Upholstery

Mobility
Smooth castor wheels with brakes

Base Type
T-shaped, anti-tip

Power Supply
110/220V AC, 50/60 Hz

About Electro-Hydraulic OT Table

Electro-Hydraulic Operating Table,Which is eccentrically positioned five section radiolucent table top,C-Arm compatible with Sliding Table Top.

Operations Positions- Height, Trendelenburg/Reverse Trendelenburg, Lateral Tilt, Back section and Table top slide which is controlled byHand held Wired Remote Control through imported hydraulic motor and solenoid valves.

Advanced Imaging Compatibility

Designed with a radiolucent tabletop, this OT table allows for clear intraoperative imaging using a C-arm. This feature is essential for procedures requiring real-time X-ray visibility, enhancing surgical accuracy and patient care without needing to move the patient.

Flexible Positioning and Ergonomics

The table offers a comprehensive range of adjustments-Trendelenburg, reverse Trendelenburg, lateral tilt, as well as flexible head, back, and leg sections. Height adjustment and modular design cater to diverse surgical procedures, ensuring optimum positioning and ergonomic comfort for the surgical team.

Reliable and Convenient Control

Operations can be managed using a handheld remote or a foot switch, providing surgeons and staff with versatile control options. Battery backup allows for uninterrupted use during power fluctuations, adding an extra layer of reliability during critical operations.

FAQ's of Electro-Hydraulic OT Table:

Q: How does the radiolucent tabletop benefit surgical procedures with C-arm imaging?

A: The radiolucent tabletop permits X-rays to pass through without interference, making it ideal for use with C-arm imaging. This allows clear, real-time imaging during surgery, crucial for procedures that require precise visual guidance.

Q: What control methods are available for adjusting the OT table during operations?

A: The table can be controlled with both a handheld remote and a foot switch. These intuitive interfaces allow for smooth, precise adjustments by the surgical team without disrupting the sterile field.

Q: When is the battery backup utilized, and how long does it last?

A: Battery backup is automatically engaged if mains power supply is interrupted. It typically provides 4-6 hours of operation, ensuring the table remains functional throughout lengthy procedures or during unexpected power outages.

Q: Where is this OT table most effectively used?

A: It is ideally suited for hospitals and medical facilities, particularly in operating rooms requiring advanced imaging and multi-positional support for a wide variety of surgical procedures.

Q: What is the maximum weight capacity of the table, and how does it ensure patient safety?

A: This table can accommodate patients up to 250 kg. Its T-shaped anti-tip base, locking castor wheels, and sturdy stainless steel construction provide maximum stability and safety during all adjustments.

Q: How easy is it to clean and maintain the OT table?

A: The table features stainless steel and composite materials, as well as an antistatic, waterproof mattress. These qualities make the surface resistant to fluids and easy to clean, supporting hygiene requirements between surgical cases.
